OnePlus 12

Design & Dimensions

• Height: Approx. 163.2 mm
• Width: Approx. 75.8 mm
• Thickness: Approx. 8.5 mm
• Weight: Approx. 220 g (including battery)
• Colors (China Version):
  • Rock Black
  • Jade Green
  • White Moon
• Craft Details:
  • Front: 2.5D Corning Gorilla Glass Victus 2
  • Back: Special-processed glass (different finishes by color)
  • Middle Frame: Aviation-grade aluminum alloy, CNC precision machining
• Water & Dust Resistance: IP65 rated (splash, water, and dust resistant under controlled lab conditions)
• Note: Dimensions and weight may vary depending on configuration, manufacturing process, and measurement method. Waterproof performance may decrease with daily wear; do not charge when wet.

Memory & Storage

• RAM Options: 12GB / 16GB / 18GB (LPDDR5X, dual-channel)
• RAM Expansion: Supports up to 16GB virtual RAM expansion (software-based)
• Storage Variants:
  • 12GB + 256GB (all colors)
  • 16GB + 256GB (all colors)
  • 16GB + 512GB (all colors)
  • 16GB + 1TB (all colors)
  • 18GB + 1TB (all colors)
• ROM Type: UFS 4.0 (sequential read up to 4200MB/s, sequential write up to 2000MB/s)
• Expandable Storage: Not supported
• OTG Data Transfer: Supported
• Note: Actual usable space is less due to system software occupation. RAM expansion combines storage with RAM to enhance multitasking.

Display – Brilliant & Fluid

• Size: 6.8-inch AMOLED 2K curved screen (rounded corners; actual visible area slightly smaller as standard rectangle)
• Resolution: 3168 × 1440 pixels (510 PPI)
• Color Depth: 10.7 Billion Colors
• Color Gamut: 100% DCI-P3 Wide Color Gamut
• Brightness:
  • Typical: 1200 nits
  • Peak (HDR): 4500 nits
  • Peak (Outdoor): 2600 nits
• Refresh Rate: 1–120Hz LTPO adaptive refresh rate (intelligently adjusts based on content)
• Touch Sampling Rate: Up to 480Hz (gaming mode) / 240Hz (normal mode)
• Screen Protection: Corning Gorilla Glass Victus 2 (front)
• Eye Comfort:
  • 2160Hz high-frequency PWM dimming (TÜV Rheinland certified)
  • Natural Color Calibration (Delta E < 1)
  • Night Mode, Reading Mode

Camera System – Capture Life in Ultra Clarity

Rear Cameras

• 50MP Main Wide Camera:
  • Sony LYT-808 sensor, 1/1.4-inch, ƒ/1.63 aperture
  • 24mm focal length equivalent, 8P lens, AF autofocus
  • OIS (Optical Image Stabilization) + EIS (Electronic Image Stabilization)
• 50MP Ultra-Wide Camera:
  • Sony IMX581 sensor, 1/2.7-inch, ƒ/2.2 aperture
  • 114° FOV, 15mm focal length equivalent, 5P lens, AF autofocus
  • Supports macro photography (2cm focus distance)
• 64MP Periscope Telephoto Camera:
  • OmniVision OV64B sensor, 1/2-inch, ƒ/3.0 aperture
  • 72mm focal length equivalent, 3x optical zoom, 6P lens
  • OIS (Optical Image Stabilization)
• Zoom Capabilities: 3x optical zoom, up to 100x digital zoom
• Supported Rear Camera Modes:
  • Photo, Video, Portrait, Night, Pro, Panorama, Time-lapse
  • Slow Motion, HDR, Super Macro, Document Scan, Dual-View Video
  • AI Scene Recognition, High-Resolution Mode, Focus Peaking (Pro Mode)
  • Long Exposure, Filter Effects, Watermark

Front Camera

• 16MP Selfie Camera:
  • Sony IMX816 sensor, ƒ/2.4 aperture, 22mm focal length equivalent
  • 5P lens, AF autofocus
• Supported Front Camera Modes:
  • Photo, Video, Portrait, Night, HDR, Panorama
  • Beauty Mode (adjustable intensity), Selfie Mirroring
  • Time-lapse, Slow Motion, High-Resolution Mode

Video Recording Capabilities

Rear Camera

• 4K Video: 60fps / 30fps (with OIS+EIS stabilization)
• 1080P Video: 60fps / 30fps (with stabilization)
• 720P Video: 30fps (with stabilization)
• Slow Motion:
  • 1080P: 240fps
  • 720P: 480fps
• Time-lapse: 4K / 1080P (30fps)
• Other Features:
  • HDR10+ Video Recording
  • Dolby Vision Video Recording
  • Movie Mode, Dual-View Video (main + ultra-wide)
  • Audio Zoom, Wind Noise Reduction

Front Camera

• 1080P Video: 30fps (with stabilization)
• 720P Video: 30fps (with stabilization)
• Time-lapse: 1080P (30fps)
• Other Features: Beauty Video, HDR Video

Performance – Flagship Speed & Efficiency

• Processor: Qualcomm Snapdragon 8 Gen 3 (4nm process)
• CPU Cores: Octa-core (1× Cortex-X4 @ 3.3GHz + 5× Cortex-A720 @ 3.0GHz + 2× Cortex-A520 @ 2.0GHz)
• GPU: Adreno 750
• OS: ColorOS 14 (based on Android 14)
• Cooling System: Circular Cold Pump Cooling System (10,000mm²+ cooling area)
• Gaming Enhancements:
  • HyperBoost Gaming Engine (frame rate stabilization, touch latency reduction)
  • X-axis Linear Motor (tactile feedback for games)
  • Stereo Dual Speakers (Hi-Res Audio certified)
  • Game Focus Mode (disturbance-free gaming)
• AI Features:
  • OnePlus AI Assistant (cross-app integration, smart queries)
  • AI Image Enhancement, AI Document Processing
  • Cross-Screen Collaboration (with Windows/Mac computers)

Battery & Charging

• Rated Capacity: 5200mAh / 20.31Wh
• Typical Capacity: 5400mAh / 20.98Wh (built-in non-removable lithium-ion polymer battery)
• Wired Fast Charging: 100W SuperVOOC Flash Charge (20V/5A)
• Wireless Charging: 50W AirVOOC Wireless Charge (Qi-compatible)
• Reverse Charging: 5W Wireless Reverse Charging
• Compatible Protocols:
  • Wired: PD 3.0, PPS, QC 4.0+
  • Wireless: Qi 1.2.4
• Note: 100W wired charging requires official OnePlus 100W SuperVOOC charger and cable. 50W wireless charging requires official OnePlus 50W AirVOOC charger. Actual charging power varies by scenario (temperature, battery level, accessories).

Security & Biometrics

• Fingerprint Sensor: In-display optical fingerprint (ultra-fast unlocking, 0.2s response)
• Face Recognition: 2D Facial Recognition (supports low-light unlocking)

Network & SIM

• SIM Type: Dual Nano-SIM (Dual Standby, Dual 5G)
• 5G Bands: n1/n2/n3/n5/n7/n8/n12/n20/n28/n38/n40/n41/n48/n66/n77/n78/n79
• 4G Bands: LTE-FDD B1/B2/B3/B4/B5/B7/B8/B12/B17/B18/B19/B20/B25/B26/B28/B32; LTE-TDD B34/B38/B39/B40/B41/B42/B46/B48
• 3G Bands: WCDMA B1/B2/B4/B5/B6/B8/B19
• 2G Bands: GSM B2/B3/B5/B8; CDMA BC0
• Note: Both SIM slots support 5G. For dual China Telecom cards, the non-data card must enable VoLTE. Network support depends on carrier deployment.

Connectivity

• Wi-Fi: Wi-Fi 7 (802.11 a/b/g/n/ac/ax/be), 2.4GHz + 5GHz + 6GHz tri-band, 4×4 MIMO, 200MHz channel width, HE160
• Bluetooth: 5.4 (supports BLE, A2DP, AVRCP, HFP, HSP, HID, SPP)
• Audio Codecs: SBC, AAC, aptX, aptX HD, LDAC, LHDC 5.0
• NFC: Multi-function NFC
  • Supports card reading (13.56MHz), eSE, HCE, NFC-SIM
  • Supports subway/bus, OnePlus Pay, access card, car key, eID
• USB Port: USB Type-C (USB 3.2 Gen 1)
• Audio Port: USB-C digital audio only (3.5mm adapter sold separately)
• Other: Infrared Remote Control, OnePlus Spatial Audio

Positioning & Navigation

• Supported Systems:
  • GPS (L1+L5 dual-band)
  • Beidou (B1I+B1C+B2a+B2b quad-band)
  • GLONASS (G1)
  • Galileo (E1+E5a+E5b tri-band)
  • QZSS (L1+L5 dual-band)
  • NavIC (L5)
• Additional Positioning: A-GNSS, WLAN positioning, cellular positioning, sensor-assisted positioning

In the Box

• 1× OnePlus 12 Smartphone
